VIP Laser Cutting Machine

The VIP laser cutting machine offers high-precision metal cutting with a powerful laser generator, advanced cutting head, flexible exchange worktable, and enhanced safety features, perfect for industrial applications.
VIP Laser Cutting Machine

$25,800.00$170,500.00

Table of Contents

Product Description

The VIP laser cutting machine is a high-performance solution designed for precision metal cutting in demanding industrial applications. Equipped with a precision laser cutting head and a high-power laser generator, it delivers clean, accurate cuts on a wide range of metals, including stainless steel, carbon steel, and aluminum. Its advanced cutting technology ensures minimal heat distortion and superior cut quality, even for intricate designs and thick materials. The flexible exchange worktable enhances productivity by allowing quick material changes, minimizing downtime, and supporting high-volume production. The aviation aluminum beam offers a perfect balance of strength and lightness, ensuring fast movement while maintaining cutting stability and precision.
For added safety, the VIP laser cutting machine features a secure closed enclosure, protecting operators from laser exposure and reducing noise during operation. The high-performance servo motors and high-precision linear guides work together to provide smooth, precise motion, ensuring accurate cuts with every operation. Equipped with an advanced control system, the VIP laser cutting machine simplifies operations, increases efficiency, and supports seamless integration into existing production lines, making it an ideal choice for industries like automotive, aerospace, and metal fabrication.

Product Configuration

Precision Laser Cutting Head

Precision Laser Cutting Head

The precision laser cutting head ensures high-accuracy cutting with exceptional focus stability. Equipped with advanced sensors and automated focus adjustment, it adapts to varying material thicknesses, delivering consistent, clean cuts. Its robust design minimizes wear and tear, enhancing the overall performance and lifespan of the fiber laser cutting machine.

High-Power Laser Generator

High-Power Laser Generator

The high-power laser generator (1-12kW) delivers exceptional cutting power, enabling fast and efficient processing of thick materials. With its superior beam quality and consistent output, it ensures precise, high-speed cuts across a wide range of metals. This powerful generator is perfect for demanding industrial applications requiring maximum performance and reliability.

Flexible Exchange Worktable

Flexible Exchange Worktable

The flexible exchange worktable enhances workflow efficiency with its quick and easy swap system, minimizing downtime between cutting jobs. Designed for seamless integration, it accommodates different material sizes and shapes, providing versatility and convenience. This feature allows for continuous operation, boosting productivity while maintaining high precision and cutting quality.

Aviation Aluminum Beam

Aviation Aluminum Beam

The aviation aluminum beam is lightweight yet incredibly strong, offering superior rigidity and durability. Engineered from high-grade aviation aluminum, it minimizes vibrations and ensures smooth, precise movement during cutting operations. This advanced material enhances overall machine performance, improving cutting speed and accuracy while maintaining long-term reliability in demanding industrial environments.

Secure Closed Enclosure

Secure Closed Enclosure

The secure closed enclosure provides a safe, controlled environment for the laser cutting process. Designed with high-quality materials, it effectively contains light and fumes, ensuring operator safety and compliance with regulations. This sturdy enclosure also minimizes noise and prevents contamination, promoting a clean, efficient, and secure working environment.

High-Performance Servo Motor

High-Performance Servo Motor

The high-performance servo motor delivers exceptional speed, precision, and reliability. Designed for seamless motion control, it ensures smooth and accurate cutting with minimal energy consumption. Its advanced technology allows for quick response times and superior positioning accuracy, making it an ideal choice for high-speed, high-precision fiber laser cutting applications.

High-Precision Linear Guides

High-Precision Linear Guides

The high-precision linear guides ensure smooth, accurate movement along the cutting axis, minimizing friction and wear. Engineered for exceptional stability and reliability, they provide consistent performance in high-speed operations. With superior alignment and minimal maintenance, these guides enhance cutting precision and contribute to the machine's overall longevity and efficiency.

Advanced Control System

Advanced Control System

The advanced control system integrates cutting-edge software with intuitive interfaces to deliver precise, real-time control over the laser cutting process. Featuring advanced algorithms and user-friendly operation, it ensures optimized cutting paths, enhanced efficiency, and consistent quality. This system boosts productivity while reducing errors, making it ideal for complex, high-speed applications.

Product Features

  • Precision Laser Cutting Head: The machine features a precision laser cutting head that ensures consistent, clean, and accurate cuts across a variety of metals, minimizing heat distortion and providing high-quality results, even for intricate designs.
  • High-Power Laser Generator: The high-power laser generator provides a steady, high-energy beam, capable of cutting through thick metals like stainless steel, carbon steel, and aluminum with exceptional precision and speed, making it ideal for heavy-duty industrial applications.
  • Flexible Exchange Worktable: The flexible exchange worktable allows for quick material changes, reducing downtime between jobs and improving productivity. This feature supports continuous operation, making the machine perfect for high-volume production environments.
  • Aviation Aluminum Beam: The machine’s lightweight but strong aviation aluminum beam provides excellent rigidity while minimizing weight. This design allows for faster movements without compromising on cutting precision, ensuring optimal performance.
  • Secure Closed Enclosure: The secure closed enclosure ensures operator safety by preventing exposure to the laser, while also minimizing noise and maintaining optimal cutting conditions within the machine’s workspace.
  • High-Performance Servo Motors: Equipped with high-performance servo motors, the machine provides fast, smooth, and precise movement along all axes. These motors ensure rapid and accurate positioning for high-quality cuts, even on complex and detailed designs.
  • High-Precision Linear Guides: The high-precision linear guides offer smooth and accurate motion, minimizing backlash and ensuring high-quality, consistent results with every cut, especially in intricate and detailed cutting tasks.
  • Advanced Control System: The advanced control system simplifies machine operation, offering real-time monitoring, enhanced user interface, and seamless integration with existing production workflows. It optimizes machine performance and enhances overall productivity.

Smart Function

Technical Parameters

Model VIP3015 VIP4015 VIP4020 VIP6015 VIP6025
Cutting Area 3000*1500mm 4000*1500mm 4000*2000mm 6000*1500mm 6000*2500mm
Laser Head Raytools, WSX, BOCI, Osprey
Laser Power 1500-20000W
Laser Generator Raycus, MAX, IPG
Control System CypCut, Weihong
Servo Motor And Driver Fuji, Delta, Yaskawa
Guide Rails Taiwan Linear Rails
Reducer Japan Shinbo, France Mortori
Max. Acceleration 1.4G 1.3G
Max. Linkage Speed 140m/min
Z Axis Travel 300mm
Positioning Accuracy 0.05mm
Repositioning Accuracy 0.03mm

Optional Configuration

Smoke Purifier System

Smoke Purifier System

The smoke purifier system is an optional configuration designed to capture and filter harmful fumes and particles generated during the laser-cutting process. By maintaining a cleaner and safer working environment, it reduces health risks and complies with environmental regulations. This system ensures optimal air quality and enhances overall machine performance.

High-Pressure Reducing Valve

High-Pressure Reducing Valve

The high-pressure reducing valve is an optional configuration that ensures precise control of gas pressure during the laser-cutting process. By regulating high-pressure gases to optimal levels, it improves cutting quality, reduces gas consumption, and enhances system safety. This feature is ideal for maintaining consistent performance across various materials.

Air Compressor

Air Compressor

The air compressor is an optional configuration that provides a consistent and reliable air supply for optimal laser-cutting performance. Designed to deliver high-pressure, clean air, it enhances cutting speed and quality, while preventing contamination of sensitive components. Ideal for high-volume operations, it ensures efficient and continuous machine performance.

Safety Light Curtain

Safety Light Curtain

The safety light curtain is an optional configuration that enhances operator safety by creating an invisible barrier around the machine. It detects any unintended entry into the cutting area, instantly halting operations to prevent accidents. This feature ensures compliance with safety standards while maintaining high productivity and machine protection.

Product Applications

The VIP laser cutting machine is designed for high-precision metal cutting and is ideal for industries requiring intricate designs and superior cut quality. Its versatile features make it perfect for metal fabrication, automotive manufacturing, aerospace, electronics, and sheet metal industries.
This machine efficiently handles stainless steel, carbon steel, aluminum, and other metals, making it suitable for custom parts production, structural components, prototyping, and industrial components. The flexible exchange worktable supports rapid material changes, enabling high-volume production runs, while the precision laser cutting head ensures detailed and intricate cuts with minimal heat distortion.
Whether for laser engraving, cutting thick metals, or creating complex geometries, the VIP laser cutting machine excels in producing high-quality results in low to high-volume production environments, optimizing both performance and productivity. It is the ideal choice for precision-driven applications in industries demanding cutting-edge technology and reliability.
Plasma Cutting VS Laser Cutting
Plasma Cutting VS Laser Cutting
Plasma Cutting VS Laser Cutting
Plasma Cutting VS Laser Cutting

Why Choose Us

Precision Cutting

Our machines deliver clean, accurate cuts every time, whether you're working with carbon steel, stainless steel, or other metals. You can count on perfect results with minimal waste.

Fast and Efficient

Victory Industry laser cutting machines are designed for speed. They cut faster, helping you get more done in less time without compromising on quality.

Cost-Effective

Our laser-cutting machines are energy-efficient and easy to maintain, helping you save money in the long run. Plus, the precise cuts reduce material waste.

Easy to Use

You don’t need a laser expert to operate our laser-cutting machines. They feature a simple interface, making them easy to set up and use.

Reliable Support

Our team is always here to help. We provide installation, training, and support to ensure your machine works smoothly.

Built to Last

Our laser cutting machines are made with durable materials, ensuring long-lasting performance, even with heavy use.
