VIC-E Laser Cutting Machine

The VIC-E laser cutting machine offers precise CO2 laser cutting with advanced features like a high-performance laser tube, efficient belt drive system, and electric lifting table, perfect for a range of materials.
VIC-E Laser Cutting Machine

$3,500.00$8,000.00

Table of Contents

Product Description

The VIC-E laser cutting machine is a high-performance CO2 laser cutting system designed for precise and efficient cutting and engraving. Equipped with an advanced CO2 laser cutting head and high-performance CO2 laser tube, this machine delivers exceptional cutting quality on a variety of materials, including acrylic, wood, plastics, and more.
Featuring a precision linear guide system and a high-precision stepper motor, the VIC-E laser cutting machine ensures smooth, accurate, and consistent cuts across the entire work surface. The efficient belt drive system guarantees reliable motion, while the electric lifting table allows for easy material handling, accommodating various material thicknesses. Additionally, the precision red dot pointer enhances accuracy during setup and cutting.
The machine is controlled by an advanced control system that simplifies operation and improves efficiency, making it suitable for a wide range of applications. Whether used for detailed engraving, intricate cutting, or large-scale production, the VIC-E laser cutting machine offers superior reliability, precision, and versatility.

Product Configuration

Advanced CO2 Laser Cutting Head

Advanced CO2 Laser Cutting Head

The advanced CO2 laser cutting head offers exceptional precision and versatility, delivering high-quality cuts across a wide range of materials. Featuring advanced optics and automated focus control, it ensures consistent, clean cuts with minimal distortion. Ideal for complex applications, it enhances performance and reduces operational costs, ensuring long-term reliability.

High-Performance CO2 Laser Tube

High-Performance CO2 Laser Tube

The high-performance CO2 laser tube delivers powerful, consistent laser output for precise cutting and engraving. Designed for durability and high efficiency, it ensures stable performance over extended periods. With excellent beam quality and energy conversion, this laser tube provides optimal cutting speeds and exceptional results on a variety of materials.

Precision Linear Guide

Precision Linear Guide

The precision linear guide ensures smooth and accurate motion during the cutting process, minimizing friction and enhancing stability. Designed for high-speed operations, it provides exceptional precision and durability, reducing wear and tear. This feature guarantees consistent performance and long-term reliability, ensuring optimal cutting quality and efficiency in demanding applications.

High Precision Stepper Motor

High Precision Stepper Motor

The high-precision stepper motor offers exceptional control and accuracy, ensuring smooth, precise movement during the laser-cutting process. With its advanced technology, it delivers consistent positioning, reducing errors and improving cutting quality. This motor enhances machine performance, providing high-speed operation with superior reliability for demanding industrial applications.

Efficient Belt Drive System

Efficient Belt Drive System

The efficient belt drive system ensures smooth, high-speed movement with minimal friction, enhancing cutting precision and reducing energy consumption. Designed for durability and low maintenance, it delivers reliable performance even in high-demand environments. This system improves overall machine efficiency, providing fast, accurate cuts while extending the lifespan of critical components.

Efficient Electric Lifting Table

Efficient Electric Lifting Table

The efficient electric lifting table provides smooth, automated height adjustment for easy material loading and unloading. With precise control and high lifting capacity, it enhances workflow efficiency and operator convenience. This feature ensures safe and ergonomic handling of workpieces, improving productivity while maintaining consistent cutting performance in various applications.

Precision Red Dot Pointer

Precision Red Dot Pointer

The precision red dot pointer is an optional feature that assists in accurate material positioning by projecting a visible red dot onto the workpiece. This guide allows operators to align materials precisely, ensuring clean, accurate cuts. It enhances workflow efficiency, reduces setup time, and ensures high-quality results, especially for intricate designs.

Advanced CO2 Cutting Control System

Advanced Control System

The advanced control system integrates cutting-edge software and hardware to optimize the laser-cutting process. With intuitive user interfaces and real-time adjustments, it ensures precise control, enhancing cutting speed and quality. This system improves operational efficiency, reduces errors, and offers advanced features for complex tasks, making it ideal for high-performance applications.

Product Features

  • Advanced CO2 Laser Cutting Head: Delivers precise, smooth cuts with minimal heat distortion, ensuring high-quality results on various materials like wood, acrylic, plastics, and more.
  • High-Performance CO2 Laser Tube: Offers a stable and powerful laser output, ensuring consistent, high-quality cuts over long periods and reducing downtime for maintenance.
  • Precision Linear Guide: Provides smooth, accurate motion during operation, reducing wear and tear while maintaining precise cutting performance for both intricate designs and high-speed tasks.
  • High Precision Stepper Motor: Ensures accurate control of the cutting head, maintaining consistent motion even during detailed and fine engraving or cutting, perfect for detailed and delicate projects.
  • Efficient Belt Drive System: Promotes fast and reliable operation with smooth acceleration and deceleration, ensuring optimal performance while reducing maintenance requirements.
  • Electric Lifting Table: Easily adjusts the height of the workpiece for different material thicknesses, improving versatility and ease of operation, particularly for large or varied materials.
  • Precision Red Dot Pointer: Assists in accurate alignment and positioning of the material for precise cuts and engravings, reducing material waste and errors.
  • Advanced Control System: User-friendly interface compatible with a variety of design software for efficient operation. It enables easy customization of settings for specific applications, enhancing productivity and workflow.

Technical Parameters

Model VIC6040E VIC9060E VIC1390E VIC1610E VIC1318E VIC1325E VIC1530E
Working Area 600*400mm 900*600mm 1300*900mm 1600*1000mm 1300*1800mm 1300*2500mm 1500*3000mm
Laser Type CO2 Laser
Working Table Knife Table or Honeycomb Table
Laser Power 80-600W
Power Supply 220V/50HZ, 110V/60HZ
Min Line Width ≤0.15mm
Position Accuracy 0.01mm
Repetition Accuracy 0.02mm
Cutting Speed 150mm/s
Control System Ruida (USB Interface)
Graphic Format Support PLT, DXF, BMP, JPG, AI, etc

Optional Configuration

Rotary Attachment

Rotary Attachment

The rotary attachment is an optional configuration that allows the CO2 laser cutting machine to cut cylindrical and round materials with precision. Perfect for processing tubes, pipes, and other curved surfaces, it expands the machine’s capabilities, providing versatility for custom applications and ensuring consistent, high-quality results across a variety of shapes.

Industrial Water Chiller

Industrial Water Chiller

The industrial water chiller is an optional configuration that provides reliable cooling for the CO2 laser cutting machine’s components, ensuring consistent performance during extended use. It helps maintain optimal temperature levels, preventing overheating and reducing the risk of damage. This feature improves cutting precision, enhances machine longevity, and minimizes downtime.

Exhaust System

Exhaust System

The exhaust system is an optional configuration designed to efficiently remove fumes, dust, and gases generated during the CO2 laser-cutting process. It helps maintain a clean, safe working environment by improving air quality and ensuring compliance with safety regulations. This system enhances machine performance and operator comfort during operation.

Gas Supply System

Gas Supply System

The gas supply system is an optional configuration that provides a steady and controlled flow of gases, such as oxygen, nitrogen, or compressed air, to the CO2 laser cutting machine. It ensures optimal cutting conditions, improves material quality, and enhances cutting efficiency, making it essential for achieving precision and high-quality results.

Product Applications

The VIC-E laser cutting machine is ideal for a wide range of industries and applications, offering precision and versatility across various materials. Its advanced CO2 laser cutting technology makes it perfect for cutting and engraving non-metal materials such as wood, acrylic, plastics, rubber, and leather. This machine excels in industries like advertising (for sign making and displays), electronics (for cutting precise components), furniture manufacturing (for intricate wood and acrylic designs), and crafts (for personalized gifts and custom engravings).
Additionally, its efficient electric lifting table allows it to handle varying material thicknesses, enhancing its flexibility for both prototype development and mass production. The VIC-E laser cutting machine is well-suited for decorative engraving, industrial prototypes, custom designs, and automotive applications, providing both high accuracy and speed. Whether for small-scale workshops or larger manufacturing operations, this machine offers high-quality results for diverse cutting and engraving needs.
Plasma Cutting VS Laser Cutting
Plasma Cutting VS Laser Cutting
Plasma Cutting VS Laser Cutting
Plasma Cutting VS Laser Cutting

Why Choose Us

Precision Cutting

Our machines deliver clean, accurate cuts every time, whether you're working with carbon steel, stainless steel, or other metals. You can count on perfect results with minimal waste.

Fast and Efficient

Victory Industry laser cutting machines are designed for speed. They cut faster, helping you get more done in less time without compromising on quality.

Cost-Effective

Our laser-cutting machines are energy-efficient and easy to maintain, helping you save money in the long run. Plus, the precise cuts reduce material waste.

Easy to Use

You don’t need a laser expert to operate our laser-cutting machines. They feature a simple interface, making them easy to set up and use.

Reliable Support

Our team is always here to help. We provide installation, training, and support to ensure your machine works smoothly.

Built to Last

Our laser cutting machines are made with durable materials, ensuring long-lasting performance, even with heavy use.
